Starter Motor Armature 594526 for FORD VALEO 12V 13T IM540 619416


● 1-Year Warranty Guarantee

● 30-45 days Lead time
The role of the starter rotor is to transmit the torque of the electric motor to the crankshaft of the diesel engine. As an intermediate hub part, its components are one-way clutch and pinion. A motor is an electric motor or an engine. The working principle is that the energized coil is forced to rotate in the magnetic field to drive the starter rotor to rotate, and the pinion on the rotor drives the engine flywheel to rotate.



Introducing the Starter Motor Armature 594526, specifically designed for FORD VALEO 12V 13T IM540 619416. This high-quality armature is an essential component for your vehicle's starter motor system.



Crafted with precision and durability in mind, this armature ensures optimal performance and reliability. It is engineered to meet the exact specifications of FORD VALEO 12V 13T IM540 619416, guaranteeing a seamless fit and seamless operation.
Availability:
Quantity:
  • IM540 619416


Product details

The role of the starter rotor is to transmit the torque of the electric motor to the crankshaft of the diesel engine. As an intermediate hub part, its components are one-way clutch and pinion. A motor is an electric motor or an engine. The working principle is that the energized coil is forced to rotate in the magnetic field to drive the starter rotor to rotate, and the pinion on the rotor drives the engine flywheel to rotate.


Introducing the Starter Motor Armature 594526, specifically designed for FORD VALEO 12V 13T IM540 619416. This high-quality armature is an essential component for your vehicle's starter motor system.


Crafted with precision and durability in mind, this armature ensures optimal performance and reliability. It is engineered to meet the exact specifications of FORD VALEO 12V 13T IM540 619416, guaranteeing a seamless fit and seamless operation.


With its professional-grade construction, this armature is built to withstand the rigors of daily use and deliver consistent power. It boasts a robust design that enhances its longevity, making it a cost-effective choice for your vehicle maintenance needs.


The Starter Motor Armature 594526 is meticulously crafted to deliver exceptional performance, ensuring a smooth and efficient starting process for your vehicle. Its 13T configuration further enhances its functionality, providing the necessary torque to kickstart your engine effortlessly.


Trust in the reliability and performance of the Starter Motor Armature 594526 for FORD VALEO 12V 13T IM540 619416. Upgrade your starter motor system with this professional-grade armature and experience enhanced starting capabilities like never before.

Application


Valeo 12-Volt 1.3kw PMGR Starters


Unit Type Part
Part Type ARMATURE - STARTER
Voltage 12
Dimension Volt 12
CE Length 17.3mm
CE Shaft Diam 6mm
Comm Diam 44.2mm
Core Diam 44.3mm
Core Length 34.8mm
DE Shaft Length 38.5mm
DE Shaft Diam 5.94mm
Pilot Length 15.8mm
# Comm Bars 23
OAL Arm 112.1mm
Spline Type Straight
# Splines 13
Manufacturer VALEO

公司大图(1)1

MFG#MFG NAME
300-40003J & N
5001-3019PIC
663-003BARSANCO
134513CARGO
6170-1011DIXIE
04314IAT
04316IAT
3019LESTER (OLD)
3262LESTER (OLD)
RAS1690RCP
186315VALEO
186917VALEO
594021VALEO
594526VALEO
NE782VALEO
W402-02WAGNER
61-9416WAI
WSA17404WOOD AUTO
